Page 109
MNVADCJ01_1729_EN
or to decrease a value; cursor to the left in text definitions
6.18.4 Preset, scan, home
(1÷7): store the present position as preset position number X
(1÷7): movement towards previously stored preset position X
: movement towards the Home position, corresponding to preset position 1
6.18.5 Pattern and “apple peel”
, , start pattern 1,2,3 ( “repeat” mode)
, , pattern 1,2,3 definition:
move the joystick and pr
ess zoom/focus to define the new pattern;
when the definition is concluded press
to save it.
, , pattern 1,2,3 erase.
start “apple peel”
6.18.6 Relays
The four relays are controlled simultaneously with special codes. The special code shows the relays to be
activated; those not shown in the code are considered deactivated. The order in which the relay numbers are
inserted in the code has no significance.
For example:
(or ) activates relays 1 and 3; relays 2 and 4 are deactivated
(or , , etc.) activates relays 1, 3 and 4; relay 2
is deactivated
deactivates all relays
