Viessmann VITOCAL Series - Recommended flexible power cables

Cable lengths in the indoor/outdoor unit
Vitocal 200-A
Cables Indoor unit Outdoor unit, types
201.A04 to A08 201.A10 to A16
Power cables – Heat pump control unit 230 V~ 1.2 m — —
– Compressor 230 V~/400 V~ — 1.2 m 1.9 m
Other connecting cables – 230 V~, e.g. for circulation
pumps
1.2 m — —
– < 42 V, e.g. for sensors 0.8 m — —
Bus cable for indoor/outdoor
unit (accessories, 15 m or 30 m)
– Modbus 0.8 m 1.2 m 1.9 m
Vitocal 222-A
Cables Indoor unit Outdoor unit, types
221.A04 to A08 221.A10 to A16
Power cables – Heat pump control unit 230 V~ 1.2 m — —
– Compressor 230 V~/400 V~ — 1.2 m 1.9 m
Other connecting cables – 230 V~, e.g. for circulation
pumps
1.2 m — —
– < 42 V, e.g. for sensors 0.8 m — —
Modbus cable for indoor/outdoor
unit (accessories, 15 m or 30 m)
– Modbus 0.8 m 1.2 m 1.9 m
Recommended flexible power cables
Indoor units Vitocal 200-A and Vitocal 222-A (all types)
Power supply Cable Max. cable length
Heat pump control unit 230 V~ – Without power-OFF
3 x 1.5 mm
2
– With power-OFF
5 x 1.5 mm
2
Instantaneous heating water heater – 400 V~
5 x 2.5 mm
2
25 m
– 230 V~
7 x 2.5 mm
2
25 m
Outdoor units, Vitocal 200-A
Vitocal 200-A Type Cable Max. cable length
230 V appliances – AWO-M
– AWO-M-E
– AWO-M-E-AC
201.A04
3 x 2.5 mm
2
29 m
201.A06
3 x 2.5 mm
2
29 m
201.A08
3 x 2.5 mm
2
29 m
201.A10
3 x 2.5 mm
2
20 m
or
3 x 4.0 mm
2
32 m
201.A13
3 x 2.5 mm
2
20 m
or
3 x 4.0 mm
2
32 m
201.A16
3 x 2.5 mm
2
20 m
or
3 x 4.0 mm
2
32 m
400 V appliances – AWO
– AWO-E
– AWO-E-AC
201.A10
5 x 2.5 mm
2
30 m
201.A13
5 x 2.5 mm
2
30 m
201.A16
5 x 2.5 mm
2
30 m
Design information
(cont.)
