6.2 Ventilation unit
Vitovent ventilation units
Vitovent mechanical ventilation systems with central ventilation unit
can be fully controlled via the heat pump control unit. The heat pump
control unit has the entire range of functions required for operation,
control parameter configuration and diagnostics of the connected
ventilation unit.
Note
For detailed information on designing a mechanical ventilation sys-
tem with a central ventilation unit: See technical guide "Central
mechanical ventilation systems with heat recovery".
Vitovent Type Part no. Countercurrent
heat exchanger
Enthalpy heat ex-
changer
Max. air flow rate in
m
3
/h
Max. residential unit
area in m
2
200-C H11S A200 Z014599 (L)
Z015391 (R)
X 200 120
H11E A200 Z014584 (L)
Z015392 (R)
X 200 120
300-W H32S B300 Z014589 X 300 230
H32E B300 Z014582 X 300 230
H32S B400 Z014590 X 400 370
H32E B400 Z014583 X 400 370
300-C H32S B150 Z014591 X 150 90
300-F H32S B280 Z011432 (w)
Z012121 (s)
X 280 180
H32E C280 Z014585 (w)
Z014586 (s)
X 280 180
(L) Supply air connection, left
(R) Supply air connection, right
(w) Colour: White
(s) Colour: Vitosilver
6.3 Heating water buffer cylinder
Vitocell 100-W, type SVPA, white
Part no. Z015310
Colour: White
Wall mounted heating water buffer cylinder for installation in the sec-
ondary circuit return
■ For storing heating water in conjunction with heat pumps with up to
17 kW heating output
■ For ensuring the minimum system volume
Standard delivery:
■ Heating water buffer cylinder with EPS thermal insulation and
sheet steel casing
■ Wall mounting bracket
■ Overflow valve DN 25, R 1
Specification
Cylinder capacity
(AT: Actual water capacity)
l 46
Max. flow temperature °C 95
Max. operating pressure bar 3
MPa 0.3
Weight kg 18
Connections (male thread)
Heating water flow and return G 1¼
Standby heat loss kWh/24 h 0.94
Energy efficiency class B
Installation accessories
(cont.)
