Viessmann VITOCAL Series - 6.4 Heating circuit (secondary circuit)

B
C
A
523
110
15 1343
A
Vitocell 100-E, type SVPA
B
Secondary circuit return in conjunction with heating circuit
hydraulic connection set, for surface mounting to right/left or
above
C
Connection line for connecting the heating water return to the
heat pump
6.4 Heating circuit (secondary circuit)
Ball valve with filter (G 1¼)
Part no. ZK03206
■ Ball valve with integral stainless steel water filter
■ For installation in the heating water return and protection of the
condenser against contamination
Installation accessories
(cont.)
60
VIESMANN
VITOCAL
6
5831388
