Note
The combination valve may be fitted on the r.h. or the l.h. side of the
boiler.
Vitoflame 100 pressure-jet gas burner in conjunction with a Vitorond 200
Rated output
of the boiler
kW 125 160 195
Burner output
First/second stage
kW 82/136 104/174 128/213
Burner type VG III-3R VG III-4R VG III-5R
Product ID CE-0085 AQ 0222
Voltage V 230
Frequency Hz 50
Power consumption W 250 340 390
Motor speed rpm 2800
Version Two-stage
Dimensions
Burner:
Length (dimension d) mm 410 430 430
Width (dimension a) mm 576 576 576
Height (dimension e) mm 596 596 596
Gas train:
Dimension f mm 288 288 288
Dimension b mm 85 85 130
Dimension g mm 63 63 15
Dimension h mm 810 810 810
Dimension c mm 500 500 545
Weight
Burner with combination valve
kg 41
Gas supply pressure mbar 20
Gas connection R (female
thread)
1 1 1¼
Connection values
in relation to the max. load
with gas with H
uB
Natural gas E
9.45 kWh/m
3
m
3
/h
14.5 18.6 22.6
34.02 MJ/m
3
Natural gas LL
8.13 kWh/m
3
m
3
/h
16.9 21.6 26.3
29.2 MJ/m
3
Approved quality
CE designation according to current EC Directives.
Burner
(cont.)
16
VIESMANN
OIL/GAS BOILERS
8
5822 426 GB
