ViewSonic IFP50-3 Series - Making Connections; HDMI and VGA Connection Guide

2121
DĂŬŝŶŐŽŶŶĞĐƟŽŶƐ
ŽŶŶĞĐƟŶŐdžƚĞƌŶĂůĞǀŝĐĞƐĂŶĚdŽƵĐŚŽŶŶĞĐƟŽŶ
or
Computer
TOUCH
VGA
TOUCH
USB Cable
USB Cable
VGA Cable
HDMI Cable
HDMI IN
zŽƵƌĞdžƚĞƌŶĂůĚĞǀŝĐĞ;ƐͿĐĂŶďĞĐŽŶŶĞĐƚĞĚŝŶĂŶLJŽĨƚŚĞĨŽůůŽǁŝŶŐĐŽŶĮŐƵƌĂƟŽŶƐ
,D/ŽŶŶĞĐƟŽŶ
To connect via HDMI:
1. Connect an HDMI cable from your external device to the HDMI IN port on the
ViewBoard.
2. Connect a USB cable to the external device from the TOUCH 1 port of the
ViewBoard.
s'ŽŶŶĞĐƟŽŶ
To connect via VGA:
1. Connect a VGA cable from your external device to the VGA port on the
ViewBoard.
2. Connect a USB cable to the external device from the TOUCH 2 port of the
ViewBoard.
