Notes:
The procedure for the association of the lock with the outdoor station described above can be repeated for a maximum
of 8 other outdoor stations. Once this limit has been reached, the attempt at defining another association will fail and
the display will exit the configuration procedure. Nevertheless, deleting the programming is possible, as described
below.
• The procedure will affect all the indoor stations and not just the one used for the definition of the association, and it
also includes any reception switchboards (for a total of 204 devices). If the entrance panel is installed on a horizontal
Bus, the procedure will affect all the indoor stations in the window (first ID - last ID) managed by the entrance panel
itself.
• The outdoor station does not exit the configuration and does not go into busy mode if in the meantime the bus is used
by a communication which has priority for the same outdoor station; the red LEDs signal that the bus is not available
and configuration continues.
Deletion of common locks configuration
Common locks
Start Procedure
Del. All
Back
1
2
Performed
1. Select "Del. All" to delete the table of common locks from the outdoor station.
2. Press to confirm.
Error
Already exists
Any errors in configuration
Error
Timeout
