ENGLISH - 41
6.4 Synchronising readers with
MASTER smart cards
The “Synchronise Readers with MASTER smart card” pro-
cedure allows several readers to operate using the same
MASTER smart card and the same MASTER code.
1 2 3 4
ON
6.4.1
Place dip-switch 2 on the reader being
synchronised in the ON position.
The LED lights up yellow.
6.3.6
When the LED turns off, the SLAVE smart
card has been programmed.
SLAVE
card
SLAVE
card
6.3.7
Remove the SLAVE smart card.
The LED turns green again, waiting for
other SLAVE smart cards to program.
To program additional SLAVE smart
cards, repeat the procedure from step
6.3.5.
6.3.8
To exit the procedure, place dip-switch
1 in the OFF position. The LED switches
off.
1 2 3
ON
Synchronising a non-initialised reader
