Vimar Plana Instruction Handbook

16 - ENGLISH
MASTER
card
MASTER
card
1 2 3 4
6
7 8
ON
4.1.6
Remove the smart card.
The LED turns green again, waiting for
other MASTER smart cards to program.
To program additional MASTER smart
cards, repeat the procedure from
step4.1.4.
4.1.7
To exit the procedure, place dip-switch
2 in the OFF position. The LED switches
off.
4.1.5
When the LED switches off, the MASTER
smart card has been programmed.
MASTER
card
MASTER
card
4.1.3
Place dip-switch 2 in the ON position.
The LED lights up yellow.
1 2 3 4
6
7 8
ON
4.1.4
When the LED turns green (after about
10 seconds), insert the smart card to be
programmed as the MASTER.
