Manual VIPA System 200V Chapter 3 Analog output modules
HB97E - SM-AIO - Rev. 12/32 3-19
The assignment of a function-no. to a certain channel happens during
parameterization.
No. Function Output range
00h Does not affect permanently stored configuration data
01h
Voltage
±10V
Siemens S5 format
(two's complement)
±12.5V
12.5V = max. value before over range (20480)
-10...10V = rated range (-16384...16384)
-12.5V = min. value before under range (-20480)
02h Voltage 1...5V
Siemens S5 format
(two's complement)
0...6V
6V = max. value before over range (20480)
1...5V = rated range (0...16384)
0V = min. value before under range (-4096)
05h Voltage 0...10V
Siemens S5 format
(two's complement)
0...12.5V
12.5V = max. value before over range (20480)
0...10V = rated range (0...16384)
no under range available
09h
Voltage
±10V
Siemens S7 format
(two's complement)
±11.76V
11.76V= max. value before over range (32511)
-10V...10V = rated range (-27648...27648)
-11.76 = min. value before under range (-32512)
0Ah Voltage 1...5V
Siemens S7 format
(two's complement)
0...5.704V
5.704V = max. value before over range (32511)
1...5V = rated range (0...27648)
0V = min. value before under range (-6912)
0Dh Voltage 0...10V
Siemens S7 format
(two's complement)
0...11.76V
11.76V = max. value before over range (32511)
0...10V = rated range (0...27648)
no under range available
03h
Current
±20mA
Siemens S5 format
(two’s complement)
±25mA
25mA = max. value before over range (20480)
-20...20mA = rated range (-16384...16384)
-25mA = min. value before under range (-20480)
04h Current 4...20mA
Siemens S5 format
(two’s complement)
0...24mA
24mA = max. value before over range (20480)
4...20mA = rated range (0...16384)
0mA = min. value before under range (-4096)
06h Current 0...20mA
Siemens S5 format
(two’s complement)
0...25mA
25mA = max. value before over range (20480)
0...20mA = rated range (0...16384)
no under range available
0Bh
Current
±20mA
Siemens S7 format
(two’s complement)
±23.52mA
23.52mA = max. value before over range (32511)
-20...20mA = rated range (-27648...27648)
-23.52mA = min. value before under range (-32512)
0Ch Current 4...20mA
Siemens S7 format
(two’s complement)
0...22.81mA
22.81mA = max. value before over range (32511)
4...20mA = rated range (0...27648)
0mA = min. value before under range (-6912)
0Eh Current 0...20mA
Siemens S7 format
(two’s complement)
0...23.52mA
23.52mA = max. value before over range (32511)
0...20mA = rated range (0...27648)
no under range available
FFh Channel not active (turned off)
Note!
The module is preset to the range "±10V voltage" in Siemens S7-format.
When cross over or underdrive range all modes return the value 0.
Function-no.
allocation
