Chapter 4 Analog input/output modules Manual VIPA System 200V
4-18 HB97E - SM-AIO - Rev. 12/32
Data input range:
During the measuring, the measuring values are stored in the data input
area with the following assignment.:
Byte Bit 7 ... Bit 0
0 High-Byte channel 0
1 Low-Byte channel 0
2 High-Byte channel 1
3 Low-Byte channel 1
4 High-Byte channel 2
5 Low-Byte channel 2
6 High-Byte channel 3
7 Low-Byte channel 3
Data output range:
For output of the data you set a value in the data output area.
Byte Bit 7 ... Bit 0
0 High-Byte channel 4
1 Low-Byte channel 4
2 High-Byte channel 5
3 Low-Byte channel 5
Data input/
data output range
