Chapter 5 238-2BC00 - Combination module Manual VIPA System 200V
5-10 HB97E - SM-AIO - Rev. 12/32
The assignment of a function no. to a certain channel happens during
parameterization. The function no. 00h does not influence the function no.
stored in the permanent parameterization data.
By entering FFh you may deactivate the concerning channel.
The following tables list all functions that are supported by the depending
channel.
You may find the corresponding connection type at the "circuit diagram"
above.
Note!
When exceeding the overdrive region, the value 7FFFh (32767) is thrown,
at underrun of the underdrive region the value is 8000h (-32768).
Input range (channel 0 … 2)
No. Function Measuring range / representation
00h Does not affect permanently stored configuration data.
7Dh Voltage 0 … 10V
Siemens S7-format
-1.76 … 11.76V
/
11.76V= End overdrive region (32511)
0...10V= nominal range (0...27648)
-1.76V= End underdrive region (-4864)
two’s complement
7Ah Voltage 1 … 5V
Siemens S7-format
0.3 … 5.70V
/
5.70V= End overdrive region (32511)
1...5V= nominal range (0...27648)
0.30V= End underdrive region (-4804)
two’s complement
28h
Voltage
±10V
Siemens S7-format
±11.76V /
11.76V= End overdrive region (32511)
-10...10V= nominal range (-27648...27648)
-11.76V= End underdrive region (-32512)
two’s complement
29h
Voltage
±4V
Siemens S7-format
±4.70V /
4.70V= End overdrive region (32511)
-4...4V= nominal range (-27648...27648)
-4.70V= End underdrive region (-32512)
two’s complement
2Ah
Voltage
±400mV
Siemens S7-format
±470mV /
470mV= End overdrive region (32511)
-400...400mV= nominal range (-27648...27648)
-470mV= End underdrive region (-32512)
two’s complement
continued ...
Function-no.
assignment
