Manual VIPA System 200V Chapter 5 238-2BC00 - Combination module
HB97E - SM-AIO - Rev. 12/32 5-11
... continue function-no. input range (channel 0…2)
7EH Current 0 … 20mA
Siemens S7-format
-3.51 … 23.51mA
/
23.51mA = End overdrive region (32511)
0...20mA = nominal range (-27648...27648)
-3.51mA = End underdrive region (-4864)
two’s complement
2Ch
Current
±20mA
Siemens S7-format
±23.51mA /
23.51mA = End overdrive region (32511)
-20...20mA = nominal range (-27648...27648)
-23.51mA = End underdrive region (-32512)
two’s complement
2Dh Current 4...20mA
Siemens S7-format
1.185...+22.81mA
/
22.81mA = End overdrive region (32511)
4...20mA = nominal range (0...27648)
1.18mA = End underdrive region (-4864)
two’s complement
FFh Channel not active (turned off)
Input range (channel 3)
No. Function Measuring range / representation
00h Does not affect permanently stored configuration data.
01h Pt100 in 2wire mode
-200 .. +850
°C /
in units of 1/10°C, two’s complement
02h Pt1000 in 2wire mode
-200 .. +500
°C /
in units of 1/10°C, two’s complement
03h NI100 in 2wire mode
-50 .. +250
°C /
in units of 1/10°C, two’s complement
04h NI1000 in 2wire mode
-50 .. +250
°C /
in units of 1/10°C, two’s complement
06h Resistance measurement
600Ohm 2wire
-
/
600Ω = Limit value (32767)
07h Resistance measurement
3000Ohm 2wire
-
/
3000
Ω = Limit value (32767)
FFh Channel not active (turned off)
