Output range (Channel 4, Ch. 5)
No. Function Output range
00h Does not affect permanently stored configuration data
09h
Voltage
±10V
Siemens S7-format
±11.76V
11.76V= End overdrive region (32511)
-10V...10V = nominal range (-27648...27648)
-11.76 = End underdrive region (-32512)
two’s complement
0Ah Voltage 1...5V
Siemens S7-format
0...5.704V
5.704V = End overdrive region (32511)
1...5V = nominal range (0...27648)
0V = End underdrive region (-6912)
two’s complement
0Dh Voltage 0...10V
Siemens S7-format
0...11.76V
11.76V= End overdrive region (32511)
0...10V = nominal range (0...27648)
no underdrive region available
0Bh
Current
±20mA
Siemens S7-format
±23.52mA
23.52mA = End overdrive region (32511)
-20...20mA = nominal range (-27648...27648)
-23.52mA = End underdrive region (-32512)
two’s complement
0Ch Current 4...20mA
Siemens S7-format
0...22.81mA
22.81mA = End overdrive region (32511)
4...20mA = nominal range (0...27648)
0mA = End underdrive region (-6912)
two’s complement
0Eh Current 0...20mA
Siemens S7-format
0...23.52mA
23.52mA = End overdrive region (32511)
0...20mA = nominal range (0...27648)
no underdrive region available
FFh Channel not active (turned off)
Note!
When exceeding the predefined range, 0V res. 0A is shown as value!
