Manual VIPA System 200V Chapter 2 Analog input modules
HB97E - SM-AIO - Rev. 12/32 2-7
Every channel is individual parameterizable. For the parameterization,
10byte parameterization data are available. The parameterization data are
stored permanently and remain also in off mode. By using the SFC 55
"WR_PARM" you may alter the parameterization in the module during
runtime. The time needed until the new parameterization is valid can last up
to 60ms. During this time, the measuring value output is 7FFFh.
The following table shows the structure of the parameter data:
Parameter area:
Byte Bit 7 ... Bit 0 Default
0, 1 reserved 00h
2 Function-no. channel 0 28h
3 Function-no. channel 1 28h
4 Function-no. channel 2 28h
5 Function-no. channel 3 28h
6...9 reserved 00h
For each channel here the function-no. of your measuring function can be
set. Please see the according table.
The function-no. 00h does not influence the function-no. stored in the
permanent parameterization data.
Assigning FFh deactivates the according channel.
No. Function Measurement range / representation
00h Does not affect permanently stored configuration data
28h
Voltage
±10V
Siemens S7 format
(two’s complement)
±11.76V /
11.76V= max. value before over range (32511)
-10...10V= nominal range (-27648...27648)
-11.76V= min. value before under range (-32512)
2Bh
Voltage
±10V
Siemens S5 format
(value and sign)
±12.50V /
12.50V = max. value before over range (20480)
-10...10V = rated range (-16384...16384)
-12.50V = min. value before under range (-20480)
3Bh
Voltage
±10V
Siemens S5 format
(two’s complement)
±12.50V /
12.50V = max. value before over range (20480)
-10...10V = nominal range (-16384...16384)
-12.50V = min. value before under range (-20480)
FFh Channel not active (turned off)
Note!
The module is preset to the range "±10V voltage"
in S7 format from
Siemens.
Parameter data
Function-no.
assignment
