Chapter 2 Analog input modules Manual VIPA System 200V
2-12 HB97E - SM-AIO - Rev. 12/32
For each channel here the function-no. of your measuring function can be
set. Please see the according table.
The function-no. 00h does not influence the function-no. stored in the
permanent parameterization data.
Assigning FFh deactivates the according channel.
No. Function Measurement range / representation
00h Does not affect permanently stored configuration data
2Ch
Current
±20mA
Siemens S7 format
(two’s complement)
±23.52mA /
23.52mA = max. value before over range (32511)
-20...20mA = rated value (-27648...27648)
-23.52mA = min. value before under range (-32512)
2Dh Current 4...20mA
Siemens S7 format
(two’s complement)
1.185 .. +22.81mA /
22.81mA = max. value before over range (32511)
4...20mA = rated range (0...27648)
1.185 mA = min. value before under range (-4864)
2Eh Current 4...20mA
Siemens S5 format
(value and sign)
0.8 .. +24.00mA /
24.00mA = max. value before over range (20480)
4 .. 20mA = rated range (0...16384)
0.8mA = min. value before under range (-3277)
2Fh
Current
±20mA
Siemens S5 format
(value and sign)
±25.00mA /
25.00mA = max. value before over range (20480)
-20...20mA = rated value (-16384...16384)
-25.00mA = min. value before under range (-20480)
39h Current 4...20mA
Siemens S5 format
(two’s complement)
0.8 .. +24.00mA /
24.00mA = max. value before over range (20480)
4 .. 20mA = rated range (0...16384)
0.8mA = min. value before under range (-3277)
3Ah
Current
±20mA
Siemens S5 format
(two’s complement)
±25.00mA /
25.00mA = max. value before over range (20480)
-20...20mA = nominal range (-16384...16384)
-25.00mA = min. value before under range (-20480)
FFh Channel not active (turned off)
Note!
The module is preset to the range "±20mA current"
in S7-format from
Siemens.
Function-no.
assignment
