Diagnostic interrupt
With the help of bit 6 of byte 0, you may release the diagnostic interrupt. In
case of an error, the record set 0 with a size of 4byte is transferred to the
superordinated system.
More detailed information is to find below under "Diagnostic data".
Function-no.
Here you set the function-no. of your measuring function for every channel.
Please see the according table above.
Option-Byte
Here you may set the transducer velocity for every input channel. Please
regard that a higher transducer velocity causes a lower resolution because
of the lower integration time.
The data transfer format remains unchanged. Only the lower Bits (LSBs)
are not longer relevant for the analog value.
Structure Option-Byte:
Byte Bit 7 ... Bit 0 Resolution Default
6 ... 7 Bit 3 ... 0: Velocity per channel*
0000 15 conversions/s
0001 30 conversions/s
0010 60 conversions/s
0011 120 conversions/s
0100 170 conversions/s
0101 200 conversions/s
0110 3.7 conversions/s
0111 7.5 conversions/s
Bit 5 ... 4: Mean value evaluation
00 deactivated
01 use 2 of 3 values
10 use 4 of 6 values
11 deactivated
Bit 7 ... 6: Envelope function
00 deactivated
01 envelope ± 8
10 envelope ±16
11 deactivated
16
16
15
14
12
10
16
16
00h
*) These specifications apply to 1channel operation. For multi-channel operations, the conversion rate
per channel can be calculated by dividing the specified conversion rate by the number of active
channels.
