VIPA System 300S - Page 106

Event ID Description
ZInfo1 : Rack/slot of the controller
ZInfo2 : Recognized ID at the configured slot
PK : Not relevant to the user
DatID : Not relevant to the user
0xEA53 PROFINET IO CONTROLLER: PROFINET configuration: There are too many PROFINET IO
devices configured
ZInfo1 : Number of configured devices
ZInfo2 : Slot
ZInfo3 : Maximum possible number of devices
0xEA54 PROFINET IO controller: IO controller reports multiple parametrization of a periphery address
ZInfo1 : Periphery address
ZInfo2 : Slot
ZInfo3 : Data width
PK : Not relevant to the user
DatID : Not relevant to the user
0xEA61 Internal error - Please contact the hotline!
0xEA62 Internal error - Please contact the hotline!
0xEA63 Internal error - Please contact the hotline!
0xEA64 PROFINET IO controller/EtherCAT-CP: Error in the configuration
ZInfo1 : Too many devices
ZInfo1 : Too many devices per second
ZInfo1 : Too many input bytes per ms
ZInfo1 : Too many output bytes per ms
ZInfo1 : Too many input bytes per ms
ZInfo1 : Too many output bytes per device
ZInfo1 : Too many productive connections
ZInfo1 : Too many input bytes in the process image
ZInfo1 : Too many output bytes in the process image
ZInfo1 : Configuration not available
ZInfo1 : Configuration not valid
ZInfo1 : Refresh time too short
ZInfo1 : Cycle time too big
ZInfo1 : Not valid device number
ZInfo1 : CPU is configured as I device
ZInfo1 : Use different method to obtain IP address Is not supported for the IP address of the
controller
ZInfo2 : Incompatible configuration (SDB version not supported)
ZInfo2 : EtherCAT: EoE configured but not supported
ZInfo2 : DC parameter not valid
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 106
