8.2 Fast introduction
The PROFIBUS DP master is to be configured in the hardware con-
figurator
. Here the configuration happens by means of the sub
module X2 (DP) of the Siemens CPU.
For the configuration of the PROFIBUS DP master please follow the
following approach:
n Hardware configuration - CPU
n Deployment as DP master or Deployment as DP slave
n T
ransfer of the complete project to CPU
Ä
Chapter 5.10
‘Project transfer’ on page 74
To be compatible to the Siemens SIMATIC Manager,
the CPU 314-6CF03 from VIP
A is to be configured as
CPU 317-2DP (6ES7 317-2AJ10-0AB0/V2.6)
The integrated PROFIBUS DP master (X3) is to be
configured and connected via the sub module X2 (DP).
The Ethernet PG/OP channel of the 314-6CF03 is
always to be configured as 1. module after the really
plugged modules at the standard bus as CP343-1
(343-1EX11) from Siemens.
8.3 Hardware configuration - CPU
The configuration of the CPU takes place at the Siemens ‘hardware
configurator
’ . The hardware configurator is part of the Siemens
SIMATIC Manager. It serves for project engineering. The modules,
which may be configured here are listed in the hardware catalog. If
necessary you have to update the hardware catalog with ‘Options
è Update Catalog’.
For project engineering a thorough knowledge of the Siemens
SIMATIC Manager and the Siemens hardware configurator is
required.
Please consider that this SPEED7-CPU has 4 ACCUs.
After an arithmetic operation (+I, -I, *I, /I, +D, -D,
*D, /D, MOD, +R, -R, *R, /R) the content of ACCU 3
and ACCU 4 is loaded into ACCU 3 and 2. This may
cause conflicts in applications that presume an
unmodified ACCU 2.
For more information may be found in the manual
"VIP
A Operation list SPEED7" at "Differences between
SPEED7 and 300V programming".
Overview
Steps of configuration
Precondition
VIPA System 300S Deployment PROFIBUS communication
Hardware configuration - CPU
HB140 | CPU | 314-6CF03 | GB | 16-43 195
