The usage of breakpoints is always possible. Switching
to the operating mode test operation is not necessary
.
With more than 2 breakpoints, a single step execution
is not possible.
5.12.2 Function security
The CPUs include security mechanisms like a W
atchdog (100ms) and
a parameterizable cycle time surveillance (parameterizable min. 1ms)
that stop res. execute a RESET at the CPU in case of an error and
set it into a defined STOP state. The VIPA CPUs are developed func-
tion secure and have the following system properties:
Event concerns Effect
RUN ® ST
OP general BASP (Befehls-Ausgabe-Sperre, i.e. com-
mand output lock) is set.
central digital outputs The outputs are disabled.
central analog outputs The outputs are disabled.
n V
oltage outputs issue 0V
n Current outputs 0...20mA issue 0mA
n Current outputs 4...20mA issue 4mA
If configured also substitute values may be
issued.
decentral outputs Same behavior as the central digital/analog
outputs.
decentral inputs The inputs are cyclically be read by the
decentralized station and the recent values
are put at disposal.
STOP ® RUN res.
PowerON
general First the PII is deleted, then OB 100 is
called. After the execution of the OB, the
BASP is reset and the cycle starts with:
Delete PIO ® Read PII ® OB 1.
decentral inputs The inputs are once be read by the decen-
tralized station and the recent values are
put at disposal.
RUN general The program execution happens cyclically
and can therefore be foreseen: Read PII ®
OB 1 ® W
rite PIO.
PII: Process image inputs, PIO: Process image outputs
VIPA System 300S Deployment CPU 314-6CF03
Operating modes > Function security
HB140 | CPU | 314-6CF03 | GB | 16-43 83
