VIPA System 300S - Page 141

No. Function Input area
23h Current 4...20mA
S7 format from Siemens
1.185...22.81mA
22.81mA = End overdrive region (3251
1)
4...20mA = Nominal range (0 ... 27648)
1.185mA = End underdrive region (-4864)
two’s complement
22h Current 0...20mA
S7 format from Siemens
0...23.52mA
23.52mA = End overdrive region (3251
1)
0...20mA = Nominal range (0 ... 27648)
no underdrive region available
00h Channel not active (turned off)
Input area (channel 4)
No. Function Input area
82h Pt100 in 2wire mode -240...1000°C
1000°C = End overdrive region (10000)
-200...+850°C = Nominal range (-2000 ... 8500)
-240°C = End underdrive region (-2400)
two’
s complement
85h Pt100 in 2wire mode -240...600°C
600°C = End overdrive region (6000)
-200...+500°C = Nominal range (-2000 ... 5000)
-240°C = End underdrive region (-2400)
two’
s complement
83h NI100 in 2wire mode -105...295°C
295°C = End overdrive region (2950)
-50...+250°C = Nominal range (-500 ... 2500)
-105°C = End underdrive region (-1050)
two’
s complement
86h NI1000 in 2wire mode -105...270°C
270°C = End overdrive region (2700)
-50...+250°C = Nominal range (-500 ... 2500)
-105°C = End underdrive region (-1050)
two’
s complement
46h Resistance measure-
ment 600Ω 2wire
0...705.5Ω
705.5Ω = End overdrive region (3251
1)
0...600Ω = Nominal range (0 ... 27648)
no underdrive region available
00h Channel not active (turned off)
VIPA System 300S Deployment I/O periphery
Analog part - Parametrization
HB140 | CPU | 314-6CF03 | GB | 16-43 141
