G4 Multi Channel Weighing Instrument
1:Rated Load
Rated load for the transducer is a value, given in the data sheet. All the transducers
in the scale must have the same impedance and rated load. The rated load value,
expressed in the unit of the data sheet, should be entered for this parameter.
If this parameter is selected for editing, the actual rated load appears on
the bottom line with a flashing cursor.
Use key ↵ to position the cursor on a digit to edit.
Then use key + or – to edit the value of the digit,
and accept each digit by key ↵ .
Press key ↵ for 1 second to accept
the edited value for rated load.
The rated load is displayed without cursor.
Now key + or – can be used
to display another parameter.
1:Rated Load
001000.000000
1
:Rated Load
1000.00
1:Rated Output 1, 2, etc.
The number of parameters 'Rated Output' corresponds to 'No of Transd.' above.
These parameter values should be set to the output signal values for the transducers,
given in the data sheets. For a fixed support point the value of the rated output should
be set to 0.00000 mV/V.
If this parameter is selected for editing, the actual rated output appears on the bottom
line with a flashing cursor.
Use key ↵ to position the cursor on a digit to edit.
Then use key + or – to edit the value of the digit,
and accept each digit by key ↵ .
Press key ↵ for 1 second to accept
the edited value for rated output.
The rated output 1 is displayed without cursor.
Now key + or – can be used
to display another parameter.
1
:Rated Output 1
2.03900 mV/V
1
:Rated Output 1
2.03900 mV/V
Enter the Rated Output value for all transducers and fixed support points in the same
way.
