Configuration Instructions
2nd caller ID#
Enter the "Caller ID" (i.e. telephone number) from which Monitoring Station #1 (C.S.1) /
Monitoring Station #2 (C.S.2) calls the control panel for initiating the Up/Download
process. If the sender's Caller ID matches with the "1
st
caller ID#" / "2
nd
caller ID#", the
PowerMaster 360 will call back the PowerManage server using "IP RCVR 1" / "IP RCVR 2"
address as configured in Section 4.6.3, options 21 and 22.
Note: Caller ID#1/ID#2 must contain at least 6 digits otherwise the process will not work.
4.6.7 Broadband
1
Note: If the Broadband Module is not registered to the PowerMaster 360, the menu "7:BROADBAND" will not be
displayed.
In this section you can configure how to obtain an IP address, enter LAN parameters and reset broadband module
settings. In addition, the “PLNK curr.params” menu enables reading the current IP addresses of the PowerLink for
support purposes only.
Enter "7:BROADBAND", select the menu to configure (see guidance above and in section 4.6.1), then refer to the
table below for configuration instructions.
Option Configuration Instructions
DHCP Client
Define whether to obtain an IP address automatically using a DHCP server or to enter an
IP address manually.
Options: disable; enable (default).
Manual IP
Manually enter LAN parameters.
Note: This menu will appear only if DHCP Client is disabled.
PLNK curr.params
Displays the current IP addresses of the PowerLink.
Curr.IP address
Displays the current PowerLink IP address.
Displays the current PowerLink subnet mask.
Current Gateway
Displays the current PowerLink default gateway.
RESET MODULE
Determine whether to reset the broadband module (reboot).
