44
Quantum Plus installation and user manual
PTZ user instructions
The telemetry function of the Quantum Plus can be controlled via 4 different methods:
1. Remote keyboard
2. Front panel buttons
3. Remote control
4. Software viewer
Remote Keyboard
–
See keyboard manual for control of PTZ cameras
Front Panel
Camera selection
The PTZ cameras can be controlled in either full screen or split screen mode. If in full
screen mode press the camera selection key , the camera icon will step from one
camera to the next on the split screen. When the icon appears on the camera to be
controlled then press the PTZ key .
If in full screen mode then simply press the PTZ key .
Pan and Tilt control
To move the dome left / right / up or down use the arrows keys .
Zoom and Focus control
To select Zoom and Focus press the Zoom Key
,
Zoom + =
Zoom - =
Focus Near =
Focus Far =
