Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-23
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
232 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
233 CB87 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
234 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
235 CB90 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
236 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
237 CB93 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
238 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
239 CB94 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
240 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
241 CB95 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
242 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
243 CB97 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
244 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
245 CB98 0111-3104-1617 C/M Multi. 0.1uF 16V X7R 0402 1
246 SS 0112-3104-1617 C/M Multi. 0.1uF 16V X7R 0402
247 C132 0111-3106-1114 C/M MULTI 10uF 10V X7R K 1206 1
248 SS 0112-3106-1114 C/M Multi. 10UF 10V X7R 1206
249 C20 0111-3104-5166 C/M MULTI 0.1UF 50V X7R J 0603 1
250 SS 0112-3104-5166 C/M Muitl. 0.1uF 50V X7R J 0603
251 C23 0111-3104-5166 C/M MULTI 0.1UF 50V X7R J 0603 1
252 SS 0112-3104-5166 C/M Muitl. 0.1uF 50V X7R J 0603
253 C26 0111-3475-1135 C/M MULTI 4.7uF 10V Y5V 0805 1
254 SS 0112-3475-1135 C/M MULTI 4.7uF 10V Y5V 0805
255 C27 0111-3475-1135 C/M MULTI 4.7uF 10V Y5V 0805 1
256 SS 0112-3475-1135 C/M MULTI 4.7uF 10V Y5V 0805
257 C28 0111-3106-1114 C/M MULTI 10uF 10V X7R K 1206 1
258 SS 0112-3106-1114 C/M Multi. 10UF 10V X7R 1206
259 C31 0111-3475-1135 C/M MULTI 4.7uF 10V Y5V 0805 1
260 SS 0112-3475-1135 C/M MULTI 4.7uF 10V Y5V 0805
261 D10 0390-5004-2343 GEN. DIODE LL4148WP SMD 1206 L-F 1
262 SS 0390-3006-7353 DIODE FAST 0.3A 100V LL4148 LL-34 LF
263 SS 0390-5004-2223 GEN. DIODE RLS4148NTE-11 SMD L-F
264 L13 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
265 L30 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
266 L33 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
267 L38 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
268 L42 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
269 L43 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
270 L49 0370-0000-6452 CHIP BEAD CORE 80ohm (MLB-201209-0080A-N2) 1
271 R100 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
272 R101 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
273 R102 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
274 R226 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
275 R227 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
276 R228 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
277 R229 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
278 R230 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
