Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-24
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
279 R231 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
280 R232 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
281 R233 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
282 R390 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
283 R391 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
284 R397 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
285 R398 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
286 R399 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
287 R400 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
288 R401 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
289 R402 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
290 R403 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
291 R404 0130-2000-1654 RES. CF 200ohm 1/16W J 0402 1
292 R407 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
