Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-39
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
655 R176 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
656 R177 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
657 R178 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
658 R179 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
659 R180 0370-0001-4773 CHIP BEAD CORE 80ohm (MCB1608H800GA) LF 1
660 R181 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
661 R182 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
662 R183 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
663 R184 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
664 R185 0370-0001-4773 CHIP BEAD CORE 80ohm (MCB1608H800GA) LF 1
665 R186 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
666 R187 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
667 R188 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
668 R189 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
669 R190 0370-0001-4773 CHIP BEAD CORE 80ohm (MCB1608H800GA) LF 1
670 R191 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
671 R192 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
672 R193 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
673 R194 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
674 R195 0370-0001-4773 CHIP BEAD CORE 80ohm (MCB1608H800GA) LF 1
675 R196 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
676 R197 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
677 R198 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
678 R199 0370-0001-4773 CHIP BEAD CORE 80ohm (MCB1608H800GA) LF 1
679 R2 0130-5600-1654 RES. CF 560ohm 1/16W J 0402 1
680 R20 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
681 R200 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
682 R201 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
683 R202 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
684 R203 0370-0001-4773 CHIP BEAD CORE 80ohm (MCB1608H800GA) LF 1
685 R204 0130-6809-1654 RES. CF 68 ohm 1/16W J 0402 1
686 R205 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
687 R206 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
688 R207 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
689 R208 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
690 R209 0131-5110-1614 RES. MF 511 ohm 1/16W F 0402 1
691 R21 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
692 R210 0130-2001-1654 RES CF 2Kohm 1/16W J 0402 1
693 R211 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
694 R212 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
695 R213 0131-5110-1614 RES. MF 511 ohm 1/16W F 0402 1
696 R214 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
697 R215 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
698 R216 0130-2001-1654 RES CF 2Kohm 1/16W J 0402 1
699 R217 0130-2002-1654 RES. CF 20Kohm 1/16W J 0402 1
700 R218 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
701 R220 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
