Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-40
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
702 R221 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
703 R222 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
704 R223 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
705 R224 0130-3300-1654 RES. CF 330ohm 1/16W J 0402 1
706 R225 0130-3300-1654 RES. CF 330ohm 1/16W J 0402 1
707 R23 0130-5600-1654 RES. CF 560ohm 1/16W J 0402 1
708 R235 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
709 R236 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
710 R237 0130-2002-1654 RES. CF 20Kohm 1/16W J 0402 1
711 R238 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
712 R239 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
713 R24 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
714 R241 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
715 R242 0130-1501-1654 RES. CF 1.5Kohm 1/16W J 0402 1
716 R243 0130-1801-1654 RES. CF 1.8Kohm 1/16W J 0402 1
717 R245 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
718 R246 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
719 R247 0130-2002-1654 RES. CF 20Kohm 1/16W J 0402 1
720 R248 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
721 R249 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
722 R251 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
723 R254 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
724 R255 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
725 R256 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
726 R257 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
727 R259 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
728 R26 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
729 R260 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
730 R261 0130-2002-1654 RES. CF 20Kohm 1/16W J 0402 1
731 R262 0130-2002-1654 RES. CF 20Kohm 1/16W J 0402 1
732 R263 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
733 R264 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
734 R265 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
735 R266 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
736 R267 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
737 R268 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
738 R269 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
739 R27 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
740 R270 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
741 R271 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
742 R272 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
743 R273 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
744 R274 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
745 R275 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
746 R276 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
747 R277 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
748 R278 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
