Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-41
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
749 R279 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
750 R28 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
751 R280 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
752 R281 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
753 R282 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
754 R283 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
755 R284 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
756 R285 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
757 R286 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
758 R287 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
759 R288 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
760 R289 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
761 R290 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
762 R293 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
763 R294 0130-6802-1654 RES. CF 68Kohm 1/16W J 0402 1
764 R295 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
765 R296 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
766 R298 0130-2702-1654 RES. CF 27Kohm 1/16W J 0402 1
767 R299 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
768 R3 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
769 R30 0130-1800-1654 RES. CF 180ohm 1/16W J 0402 1
770 R304 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
771 R307 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
772 R308 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
773 R309 0130-3001-1654 RES. CF 3 Kohm 1/16W J 0402 1
774 R31 0130-1100-1654 RES. CF 110ohm 1/16W J 0402 1
775 R310 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
776 R315 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
777 R317 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
778 R319 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
779 R32 0130-1100-1654 RES. CF 110ohm 1/16W J 0402 1
780 R320 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
781 R321 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
782 R322 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
783 R325 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
784 R326 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
785 R327 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
786 R329 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
787 R33 0130-1800-1654 RES. CF 180ohm 1/16W J 0402 1
788 R330 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
789 R331 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
790 R333 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
791 R334 0130-3908-1858 RES. CF 3.9ohm 1/8W J 0805 1
792 R335 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
793 R336 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
794 R337 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
795 R338 0130-3908-1858 RES. CF 3.9ohm 1/8W J 0805 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
