Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-42
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
796 R34 0130-1100-1654 RES. CF 110ohm 1/16W J 0402 1
797 R340 0130-3908-1858 RES. CF 3.9ohm 1/8W J 0805 1
798 R341 0130-3908-1858 RES. CF 3.9ohm 1/8W J 0805 1
799 R342 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
800 R343 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
801 R344 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
802 R345 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
803 R346 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
804 R347 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
805 R35 0130-1201-1654 RES. CF 1.2Kohm 1/16W J 0402 1
806 R352 0130-0000-1858 RES. CF 0.0ohm 1/8W J 0805 1
807 R353 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
808 R354 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
809 R358 0130-4703-1654 RES. CF 470Kohm 1/16W J 0402 1
810 R359 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
811 R36 0130-1800-1654 RES. CF 180ohm 1/16W J 0402 1
812 R360 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
813 R361 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
814 R362 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
815 R364 0130-7509-1654 RES. CF 75ohm 1/16W J 0402 1
816 R366 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
817 R367 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
818 R369 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
819 R37 0130-2001-1654 RES CF 2Kohm 1/16W J 0402 1
820 R370 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
821 R371 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
822 R372 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
823 R373 0130-2002-1654 RES. CF 20Kohm 1/16W J 0402 1
824 R375 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
825 R377 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
826 R378 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
827 R379 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
828 R38 0130-3001-1654 RES. CF 3 Kohm 1/16W J 0402 1
829 R380 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
830 R382 0112-3105-1157 C/M Multi. 1.0uF 10V X5R 0402 1
831 R383 0112-3105-1157 C/M Multi. 1.0uF 10V X5R 0402 1
832 R384 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
833 R385 0130-4703-1654 RES. CF 470Kohm 1/16W J 0402 1
834 R386 0130-4703-1654 RES. CF 470Kohm 1/16W J 0402 1
835 R387 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
836 R39 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
837 R393 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
838 R394 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
839 R395 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
840 R396 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
841 R4 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
842 R40 0130-1100-1654 RES. CF 110ohm 1/16W J 0402 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
