Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-43
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
843 R406 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
844 R408 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
845 R41 0130-1003-1654 RES. CF 100Kohm 1/16W J 0402 1
846 R42 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
847 R43 0130-1200-1654 RES. CF 120ohm 1/16W J 0402 1
848 R44 0130-1100-1654 RES. CF 110ohm 1/16W J 0402 1
849 R45 0130-1800-1654 RES. CF 180ohm 1/16W J 0402 1
850 R46 0130-1100-1654 RES. CF 110ohm 1/16W J 0402 1
851 R47 0130-1003-1654 RES. CF 100Kohm 1/16W J 0402 1
852 R48 0130-2209-1654 RES. CF 22ohm 1/16W J 0402 1
853 R49 0130-3001-1654 RES. CF 3 Kohm 1/16W J 0402 1
854 R5 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
855 R50 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
856 R51 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
857 R52 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
858 R53 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
859 R54 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
860 R55 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
861 R56 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
862 R57 0130-1003-1654 RES. CF 100Kohm 1/16W J 0402 1
863 R58 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
864 R59 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
865 R60 0130-2203-1654 RES. CF 220Kohm 1/16W J 0402 1
866 R62 0130-1000-1654 RES. CF 100ohm 1/16W J 0402 1
867 R63 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
868 R64 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
869 R65 0130-1003-1654 RES. CF 100Kohm 1/16W J 0402 1
870 R66 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
871 R68 0131-6341-1614 RES. MF 6.34 Kohm 1/16W F 0402 1
872 R69 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
873 R7 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
874 R70 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
875 R71 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
876 R72 0130-1004-1654 RES. CF 1Mohm 1/16W J 0402 1
877 R73 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
878 R74 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
879 R75 0130-1001-1654 RES. CF 1Kohm 1/16W J 0402 1
880 R78 0130-5600-1654 RES. CF 560ohm 1/16W J 0402 1
881 R8 0130-4702-1654 RES. CF 47Kohm 1/16W J 0402 1
882 R83 0130-4709-1654 RES. CF 47ohm 1/16W J 0402 1
883 R85 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
884 R86 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
885 R88 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
886 R9 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
887 R91 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
888 R92 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1
889 R93 0130-3309-1654 RES. CF 33ohm 1/16W J 0402 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
