Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-44
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
890 R94 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
891 R95 0130-1002-1654 RES. CF 10Kohm 1/16W J 0402 1
892 R96 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
893 R97 0130-4701-1654 RES. CF 4.7Kohm 1/16W J 0402 1
894 R98 0130-8201-1654 RES. CF 8.2Kohm 1/16W J 0402 1
895 R99 0130-0000-1654 RES. CF 0ohm 1/16W J 0402 1
896 U1 0420-1005-4601 POWER MOS IRF7316TRPBF SMD 8PIN LF 1
897 U10 0430-6006-1079 IC LDO AP1084KLA ADJ TO-263-3L LF 1
898 U11 0430-1002-0015 IC CMOS SN74HC00DR SOIC 14PIN LF 1
899 SS 0430-1002-0009 IC CMOS 74HC00D SO14 LF
900 U13 0430-7043-1999 IC DEMODULATOR MT5112BD LQFP 100PIN LF 1
901 U14 0430-7043-6999 IC SCALER MT5372AJ-L BGA 588PIN LF 1
902 U15 0430-6015-6099 IC RESET STL8110GCL438 4.38V SOT-23 3PIN LF 1
903 U16 0430-3039-4645 IC MX29LV320CTTC-70G 48PIN TSOP LF 1
904 U17 0430-3004-3011 IC AT24C16AN-10SU-2.7 SO-8 L-F 1
905 U18 0430-7031-9603 IC DDR 16Mx16 NT5DS16M16CS-5T 66PIN TSOPII LF 1
906 U19 0430-7031-9603 IC DDR 16Mx16 NT5DS16M16CS-5T 66PIN TSOPII LF 1
907 U2 0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF 1
908 U20 0430-6010-9028 IC G2996F1Uf 8PIN SOP-8(FD) LF 1
909 U21 0430-3039-6011 IC AT24C02BN-10SU-1.8 8Pin SOIC L-F 1
910 U22 0430-7044-1092 IC SWITCH PI3HDMI412FTZHE TQFN 42PIN LF 1
911 U23 0430-3039-6011 IC AT24C02BN-10SU-1.8 8Pin SOIC L-F 1
912 U24 0430-7043-5092 IC SWITCH PI5C3257QE QSOP 16PIN LF 1
913 U25 0430-3039-6011 IC AT24C02BN-10SU-1.8 8Pin SOIC L-F 1
914 U27 0430-0001-8015 IC CD4052BNSR 16PIN SOP16 L-F 1
915 SS 0430-0002-9086 IC CMOS 4052L-S16-R SOP 16PIN LF
916 U28 0430-7027-3699 IC WM8776SEFT 48PIN TQFP L-F 1
917 U30 0430-7043-7099 IC AUDIO DAC WM8521HCGED SOIC 14PIN LF 1
918 U32 0420-1005-4601 POWER MOS IRF7316TRPBF SMD 8PIN LF 1
919 U33 0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF 1
920 U34 0430-6015-8079 IC DC/DC CONVERTER AP1522WA SOT23-5 5PIN LF 1
921 U4 0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF 1
922 U5 0430-6015-5079 IC STEP DOWN CONVERTER AP1513SA SOP 8PIN LF 1
923 U6 0430-6015-5079 IC STEP DOWN CONVERTER AP1513SA SOP 8PIN LF 1
924 U7 0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF 1
925 U8 0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF 1
926 U9 0430-6009-1051 IC AMC1117SKF-ADJ SMD 3PIN SOT-223 LF 1
927 X1 0286-2700-0024 OSC 27MHz 25ppm 3.3V SMD VCXO 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
