Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-13
File No. SG-0204
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
44 CE52 0103-1100-1511 E/C VT 10uF 50V 105'C F-T
(
5*11mm
)
1
45 CE53 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
46 CE54 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
47 CE55 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
48 CE56 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
49 CE57 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
50 CE58 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
51 CE59 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
52 CE6 0103-1221-1311 E/C VT 220uF 25V 105'C F-T (8*11.5mm) 1
53 CE60 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
54 CE62 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
55 CE64 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
56 CE65 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
57 CE66 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
58 CE67 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
59 CE7 0103-1221-1311 E/C VT 220uF 25V 105'C F-T (8*11.5mm) 1
60 CE72 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
61 CE75 0103-1221-1311 E/C VT 220uF 25V 105'C F-T (8*11.5mm) 1
62 CE78 0230-5008-0000 JUMPER WIRE 5.0*0.6MM 1
63 CE79 0230-5008-0000 JUMPER WIRE 5.0*0.6MM 1
64 CE8 0103-1221-1311 E/C VT 220uF 25V 105'C F-T (8*11.5mm) 1
65 CE81 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
66 CE82 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
67 CE83 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
68 CE84 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
69 CE87 0103-6102-1212 E/C HF 1000uF 16V 105'C F (10*20) 1
70 SS 0103-6102-1210 E/C HF 1000uF 16V 105'C N-F (10*20)
71 CE88 0103-1220-1511 E/C VT 22uF 50V 105'C F-T (5*11mm) 1
72 CE89 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
73 CE9 0103-1221-1311 E/C VT 220uF 25V 105'C F-T (8*11.5mm) 1
74 CE90 0103-1220-1511 E/C VT 22uF 50V 105'C F-T (5*11mm) 1
75 CE91 0103-1221-1311 E/C VT 220uF 25V 105'C F-T (8*11.5mm) 1
76 C159 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
77 C160 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
78 C161 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1
79 C33 0103-1101-1211 E/C VZ 100uF 16V 105'C F-T (5*11mm) 1
80 C34 0103-1101-1211 E/C VZ 100uF 16V 105'C F-T (5*11mm) 1
81 C38 0103-1100-1511 E/C VT 10uF 50V 105'C F-T (5*11mm) 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
