Vizio VX32L Service Manual

CONFIDENTIAL – DO NOT COPY Page 12-14
File No. SG-0204
363200620150M MAIN BD ASS'Y VX32L HDTV_LG MI
ITEM M/S LOCATION PART NO. DESCRPTION
Q
TY
1 J1 0451-2000-1366 WAFER 2.0mm 13P 90' DIP KINK
(
M242613R
)
L-F 1
2 SS 0451-2003-1363 WAFER 2.00mm 13P 90' KINK (A2001WR2-13P) L-F
3 J2 0451-1250-1066 WAFER 1.25mm 10P 90' DIP KINK (M240110R) L-F 1
4 SS 0451-1250-1063 WAFER 1.25mm 10P 90' KINK (A1251WR0-10P) L-F
5 J4 0451-2000-1266 WAFER 2.0mm 12P 90' DIP KINK (M242612R) L-F 1
6 SS 0451-2003-1263 WAFER 2.00mm 12P 90' KINK (A2001WR2-12P) L-F
7 J6 0451-2500-0446 WAFER 2.5mm 4P 90' DIP KINK (M241854R) L-F 1
8 SS 0451-2500-0443 WAFER 2.50mm 4P 90' KINK (A2501WR2-4P) L-F
9 L11 0361-2022-0030 COIL CHOKE 22UH 2.9A 11*12 DIP 1
10 L68 0370-0000-1011 FERRITE CORE RH 3.5X6X1.0(W)X2 L-F 1
11 L8 0361-2022-0030 COIL CHOKE 22UH 2.9A 11*12 DIP 1
12 P1 0302-9060-0020 RCA JACK 2ROW 6I/O (G-B-R) 1
13 P10 0300-6400-0031 OPTO CONN. Transmitter (134-0029-399A) L-F 1
14 P11 0302-9030-0114 RCA JACK 1ROW 3I/O (Y-W-R) L-F 1
15 P2 0302-9040-0010 RCA JACK 2ROW 4I/O 90' (W-R) L-F 1
16 P3 0300-1205-3151 D-SUB FEMALE 90' 15P 3ROW (DV11201-H5R6-4F) L-F 1
17 P4 0302-0350-0012 PHONE JACK 3.5 φ 5P 90' +SHIELD L-F 1
18 P5 0202-6000-0003 RJ11 6P6C Gray UNDER CONTACT L-F 1
19 P8 0302-9020-0114 RCA JACK 2ROW 2I/O (W-R) L-F 1
20 P9 0302-9020-0114 RCA JACK 2ROW 2I/O (W-R) L-F 1
21 SW1 0220-7020-0130 SW TACT 6*6mm 180' 160g SFKHHAM2525 L-F 1
22 U12 0980-0103-3060 MODULE TUNER DTVS205CH201A L-F 1
23 U3 0430-6011-3210 IC MC7805CTG 3PIN TO-220 LF 1
24 SS 0430-6011-3204 IC LM7805CT TO-220 3PIN LF
25 U31 0430-4013-3109 IC TDA8946AJ 17PIN DIP LF 1
26 Y1 0280-2500-0012 X'TAL 25MHZ 49/US 30PPM 20PF LF 1

Vizio VX32L Specifications

Display

native resolution	1366 x 768
brightness	500 cd/m2
contrast ratio	1200:1
response time	8 ms

Connectivity

HDMI inputs	2
component inputs	2
S-Video inputs	1
composite video inputs	2
RGB (PC) inputs	1

Weight and Dimensions

diagonal screen size	32 inches
width with stand	31.4 inches
height with stand	23.3 inches
depth with stand	8.6 inches
width without stand	31.4 inches
height without stand	22.1 inches
depth without stand	3.9 inches
weight with stand	32 lbs
weight without stand	31 lbs
