Technical information
GB
D700/750 E2-E3
D703
IDM-45300900300.tif
Extraction
collector
(L)
Oil filter (G)
Heat exchanger (A)
Alternating current gen-
erator
(Q)
Thermostatic valve (E)
Injector (C)
Turbocharger (B)
Waste-gate valve (D)
Fuel filter (F)
Water pump (M)
Transmission belt (N)
Exhaust manifold (S)
Water collector (T)
Oil sump (H)
Starter motor (R)
Injection pump (P)
