pg. 18
VOLCON BRAT OWNER’S MANUAL
Top Speed *28+ mph
Range **70+ miles
Weight 86 lbs.
Motor 750w/1200w max
Battery 48V/15.6ah removable
Charge Time 6-7 hrs. (3 amp)
Tires 20x4.0
Tubes 20x4
Front Suspension Adjustable inverted fork
Rear Suspension Adjustable mono-shock
Brakes Hydraulic disc
Display 4 ride modes, Bluetooth compatible, D-Pad
connected
Classications ***The Brat is a Class 2 e-bike with multi-
mode capability
Weight Capacity 340 lbs. (154 kg)
* Fully unlocked in unlimited off-road mode
** In ECO mode. However, variables such as rider weight, temperature, terrain, pedal
input and usage will affect the overall range.
*** Class 1 will be available on each bike when in mode 1. A fully unlocked/unlimited
off-road mode will also be available in the app (after each customer conrms waiver of
acknowledgment).
Table 1 - Technical Specifications
TECHNICAL SPECIFICATIONS & FEATURES
