pg. 22
VOLCON BRAT OWNER’S MANUAL
NOTE: If your Brat is delivered directly to you, it will come partially assembled
and will need to be assembled with the following parts.
Tools and Hardware
Included
Parts Fasteners Tools
1 x Handlebar set 4 x 5mm Allen Bolts 2.5mm Allen Wrench
2 x Pedals 2 x 14mm Hex Head bolts 3mm Allen Wrench
1 x Headlight 5 x 3mm Allen Bolts 5mm Allen Wrench
1 x Front Fender 1 x 8mm Allen bolts 8mm Allen Wrench
1 x Rear Fender 14/15mm Box Wrench
1 x Kickstand Phillips Head Screwdriver
Table 2 - Tool and Parts List
Figure 8 - Bike Assembly
WHAT’S IN THE BOX
To Next Page
