VOLCON BRAT - Ride Mode Selection; Ride Mode Selector Overview; Ride Mode Configuration

VOLCON BRAT OWNER’S MANUAL
pg. 41
Selecting a Ride Mode
Figure 24 - Ride Mode Selector
1. When you power on your e-bike for the rst time, the bike will be on level 1 ride
mode.
NOTE: This mode is a pedal assist only mode and the throttle will not be
activated when this mode is being used.
2. Press the (+) button on the D-Pad to change up to the next ride mode (press
the (-) button to go down a ride mode).
3. Repeat this process eventually going up to mode 4.
MODE INPUT PEDAL
ASSIST
OUTPUT (PAS)
THROTTLE
OUTPUT
TOP SPEED
(MPH)
2 PEDAL/THROTTLE 75% 50% 20
3 PEDAL/THROTTLE 95% 75% 20
4 PEDAL/THROTTLE 95% 100% 20
Table 3 - Ride Modes
