VOLCON BRAT OWNER’S MANUAL
pg. 27
Pedal Installation
Figure 14 - Pedal Installation
Figure 15 - Left and Right Pedal
1. Separate the left and right pedals marked with (R) and (L). (Figure 15)
2. Install the left pedal (non-chain side) by spinning it counter clockwise.
3. Install the right pedal (chain side) by spinning it clockwise.
4. Rotate the pedal slowly by hand rst to avoid cross threading.
5. Tighten the pedal with the 15mm box wrench.
