5.Panel Operation
49
Pulse Rising Time 1.953 us
Pulse Falling Time 1.953 us
Build-in Wave X^2
Modulation Waveform Factory Setting
Modulation type AM
AM
Modulating Waveform Sine
AM Frequency 100 Hz
Modulation Depth 100%
Modulation Source Internal
FM
Modulating Waveform Sine
FM Frequency 100 Hz
Frequency Deviation 100 Hz
Modulation Source Internal
PM
Modulating Waveform Sine
PM Frequency 100 Hz
Phase Deviation 0°
Modulation Source Internal
PWM
Modulating Waveform Sine
PWM Frequency 100 Hz
Duty Cycle Deviation 0%
Modulation Source Internal
ASK
ASK Rate 100 Hz
Modulating Amplitude 1 Vpp
Modulation Source Internal
PSK
PSK Rate 100 Hz
PSK Phase Deviation 0°
Modulation Source Internal
FSK
