7.Specification
54
8. Specification
All technical specifications are guaranteed when the following conditions are
met, unless otherwise stated.
 The signal generator must be operated continuously for more than 30
minutes at the specified operating temperature (20°C to 30°C) to meet
these specifications；
 The signal generator is in the calibration internal and has performed a
self-calibration.
In addition to the specifications marked with the word "Typical", the
specifications used are guaranteed.
Waveforms
Waveforms
Bandwidth
FG-1302
30 MHz
FG-1602 60 MHz
Sample Rate
FG-1302
125MSa/s
FG-1602 300MSa/s
Vertical Resolution 14 bits
Channel
2
Standard
Waveforms
Sine wave, square wave, ramp wave, pulse wave, noise
Arbitrary
Waveforms
Sinc, exponential rise, exponential decline, electrocardiogram,
Gaussian, semi-positive, Lorentz, dual audio, DC voltage totaling
more than 160 kinds
Frequency Characteristics
Frequency Characteristics (Frequency resolution to 1 μHz)
Sine wave
FG-1302
1 μHz ~ 30MHz
FG-1602 1 μHz ~ 60MHz
Square wave
FG-1302 1 μHz ~ 15MHz
FG-1602
1 μHz ~ 20MHz
Pulse wave
FG-1302 1 μHz ~ 15MHz
FG-1602
1 μHz ~ 20MHz
Ramp wave
FG-1302
1 μHz ~ 1 MHz
FG-1602 1 μHz ~ 2 MHz
Noise wave (-3 dB)
20 MHz BW（AWGN）
Arbitrary wave 1 μHz - 10 MHz
Frequency
resolution
1 μHz or 7 significant figures
