7.Specification
56
FG-1602
Typical (0dBm)
DC to 1MHz: <-65dBc
1MHz to 35MHz: <-60dBc
35MHz to 60MHz: <-50dBc
Total harmonic
distortion
< 0.2 %, 10 Hz to 20 kHz, 1 Vpp
Non-harmonic
distortion
Typical (0dBm)
≤10MHz: <-70dBc
>10MHz: <-70dBc + 6dB/ sound interval
Phase noise
Typical (0dBm, 10kHz offset)
10MHz: ≤ -110dBc/Hz
Square
Rise/fall time
< 20ns
Jitter (rms), typical
(1Vpp, 50Ω)
200ps + 30ppm
Overshoot
< 5%
Ramp
Linearity
< 1% of peak output
(typical 1 kHz, 1 Vpp, symmetry 50%)
Symmetry 0% to 100%
Pulse
Period
FG-1302 67 ns to 1 Ms
FG-1602
50 ns to 1 Ms
Pulse Width ≥ 24ns
Rise and fall time ≥ 15ns
Overshoot
< 5%
Jitter (rms), typical
(1Vpp, 50Ω)
200ps + 30ppm
Noise
Types Gaussian white noise
Bandwidth (-3dB)
20 M
Arbiratry wave
Bandwidth
10M
Waveform length 2 to 100K points
Sampling rate
FG-1302 125Ma/s
FG-1602
300Ma/s
Amplitude accuracy 14 bits
Modulation Characteristics
Modulation Characteristics
Modulation Type
AM, DSBAM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK,
4FSK, OSK, PWM, SUM
