7.Specification
60
Burst Characteristics
Burst Characteristics
Waveform
Sine wave, square wave, ramp wave, pulse wave and arbitrary
wave (Except DC)
Types
N-cycle,Gated
N-cycle trigger
source
Internal, external, manual
Carrier frequency 1 μHz to Maximum frequency of corresponding carrier /2
N-cycle trigger cycle
FG-1302
67 ns ～ 1 Ms（Min = Cycles * Period）
FG-1602
34 ns ～ 1 Ms（Min = Cycles * Period）
periodicity
1 ～ 60000（Max =Burst Period / Period）/infinite
Gated source
External trigger
Counter Specifications
Counter Specifications
Measurement function Frequency, period
Frequency Range
Single channel :100 mHz - 200 MHz
Frequency resolution 6 digits
Input resistance
1 MΩ
Input/Output Characteristics
Input/Output Characteristics
Communication Interface USB Host, USB Device
External modulation input
Input frequency range DC - 20 kHz
Input level range
± 1V full scale
Input impedance 10 kΩ (typical)
External trigger input
Level
TTL-compatible
Slope Rising or falling (selectable)
Pulse Width
>100ns
Sync Output
Level TTL-compatible
Maximum frequency
1MHz
General Specifications
Display
Display type
3.6-inch color LCD display
Display resolution 480 Horizontal ×272 Vertical pixels
