Volvo Penta D1-13 - Page 12

Fuel injection pump:
Mounting nuts and bolts 6 Nm (4.4 lbf.ft.)
Supply valve retainer 42 Nm (31.0 lbf.ft.)
Delivery pipe (cylinder block - cylinder head) 12 Nm (8.9 lbf.ft.)
Injectors 64 Nm (47.2 lbf.ft.)
Feed line:
D1-13-A/B/F, D1-20-A/B/F, D2-40-A/B/F 20 Nm (14.8 lbf.ft.)
D1-30-A/B/F 23 Nm (17.0 lbf.ft.)
Lock screw (maximum fuel volume) 13–16 Nm (9.6–11.8 lbf.ft.)
Lock screw (speed) 13–16 Nm (9.6–11.8 lbf.ft.)
Exhaust Manifold 10 Nm (7.4 lbf.ft.)
Fuel shut-off solenoid 17 Nm (12.5 lbf.ft.)
Fuel pump
Adjuster screw 2.5 Nm (1.8 lbf.ft.)
Mounting screws 6 Nm (4.4 lbf.ft.)
Glowplugs 11.5 Nm (8.5 lbf.ft.)
Oil pressure contact and adapter 11 Nm (8.1 lbf.ft.)
Coolant temperature contact 27 Nm (19.9 lbf.ft.)
Coolant drain plug (plastic) 3 Nm (2.2 lbf.ft.)
Coolant thermostat housing 14 Nm (10.3 lbf.ft.)
Oil pressure relief valve 64 Nm (47.2 lbf.ft.)
Start motor, contacts 9.8–11.8 Nm (7.2–8.7 lbf.ft.)
General tightening torque values
M5 5 Nm (3.7 lbf.ft.)
M6 10 Nm (7.4 lbf.ft.)
M7 17 Nm (12.5 lbf.ft.)
M8 24 Nm (17.7 lbf.ft.)
M10 50 Nm (36.9 lbf.ft.)
M12 80 Nm (59.0 lbf.ft.)
M14 130 Nm (95.9 lbf.ft.)
03-2 Specifications, Engine
10 47701798 05-2013 © AB VOLVO PENTA
