Lubrication System
Group 22: Lubrication System
Oil pressure, hot engine at high idle 196–441 kPa (28.4–64.0 PSI)
Oil pressure, hot engine at low idle >48 kPa (7 PSI)
Oil pressure relief valve, opening pressure:
D1-13-A/B/F, D1-20-A/B/F 352–448 kPa (51–65 PSI)
D1-30-A/B/F, D2-40-A/B/F 304–500 kPa (44–73 PSI)
Oil pump
Clearance between inner and outer rotors 0.01–0.15 mm (0.0004–0.0059")
Service limit 0.25 mm (0.0098")
End float between oil pump cover surface and intermedi-
ate gearwheel surface 0.01–0.15 mm (0.0004–0.0059")
Service limit 0.20 mm (0.0079")
Shims available for adjustment of end float 0.10, 0.15, 0.20, 0.50 mm
(0.0039, 0.0059, 0.0079, 0.0200")
Oil grade according to API system VDS-2
ACEA E7
API CH-4
Viscosity at –5 to +50°C (23°F to 122°F)* SAE 15W/40
SAE 20W/50
Maximum oil volume, excl. oil filter, no engine incline:
D1-13-A/B/F 1.9 l (0.50 US gals)
D1-20-A/B/F 2.8 l (0.74 US gals)
D1-30-A/B/F 3.5 l (0.92 US gals)
D2-40-A/B/F 6.5 l (1.72 US gals)
Oil change interval:
D1-13-A/B/F, D1-20-A/B/F, D1-30-A/B/F 200 hours or 12 months
D2-40-A/B/F 200 hours or 12 months
NOTICE! * Temperatures at stable ambient temperature.
03-2 Specifications, Engine
20 47701798 05-2013 © AB VOLVO PENTA
