Connecting rod journals
D1-13-A/B/F, D1-20-A/B/F
Diameter, journal:
Standard 34.964–34.975 mm (1.3765–1.3770")
Service limit 34.90 mm (1.3740")
NOTICE! No undersize connecting rod journals are available.
D1-30-A/B/F, D2-40-A/B/F
Diameter, journal:
Standard 40.964–40.975 mm (1.6128–1.6132")
Service limit 40.90 mm (1.6102")
NOTICE! No undersize connecting rod journals are available.
Clearance between connecting rod bearing and connecting rod journal, standard play
D1-13-A/B/F, D1-20-A/B/F 0.031–0.079 mm (0.00122–0.00311")
D1-30-A/B/F, journal #. 1 and 2 0.039–0.092 mm (0.00150–0.00360")
D1-30-A/B/F, journal #. 3 0.029–0.082 mm (0.00110–0.00320")
D2-40-A/B/F 0.039–0.092 mm (0.00150–0.00360")
Service limit, all engines 0.20 mm (0.0079")
Con rods
Piston pin bearing
Clearance between piston pin and piston pin bearing 0.010–0.025 mm (0.00040–0.00099")
Service limit, D1-13-A/B/F, D1-20-A/B/F 0.10 mm (0.004")
Service limit, D1-30-A/B/F, D2-40-A/B/F 0.08 mm (0.0031")
Connecting rod bearings
Clearance between connecting rod bore and connecting
rod bearing 0.10–0.30 mm (0.004–0.012")
Service limit 0.70 mm (0.0276")
Camshaft
Drive Gear wheel
Cam lobe height for inlet and exhaust valves, all engines 26.955–27.010 mm (1.0612–1.0634")
Service limit 26.5 mm (1.0430")
Cam lobe height for fuel injection pump 39.900–40.100 mm (1.5709–1.5787")
Service limit 39.8 mm (1.5669")
Cam lobe height for hand fuel pump 27.900–28.000 mm (1.0984–1.1024")
Service limit 27.0 mm (1.0630")
03-2 Specifications, Engine
18 47701798 05-2013 © AB VOLVO PENTA
