Volvo D24 - Page 78

Group 21 Engine
Cafishaft,
installing
Make sure
cyl. 1 is at
TDC
Check'0'mark
on
flywheel and adiust
if necessary'
N12
Set camshaft
position
Place
gauge
5190 at rear of camshaft. Insert a 0.2 mm
feeler
gauge
beneath
left
side of
gauge
to compensate
for timing
gear
clearance.
Qi
0
(
(
Tighten
camshaft
lront sprocket
use 5199 to
prevent
sprocket
from lurning.
Torque center bolt to 45 Nm
(33
ft
lbs).
N13
Remove
gauge
5190 and
feeler
gauge
0)l
I
0)
a
N15
Disconnect
cold start device
Slacken screw L Push lever
forward and rotate s eeve
90'.
Noiel Do notturn
screw2 otherwise it will be necessary
to remove
cold start device and reset it
on a test bench.
Press
back lever againsr
stop.
16
