SECTION 5 MAINTENANCE INSTRUCTIONS
5-26 DD-29/31HF/38HF Vibratory Asphalt Compactors
8. Clean drain plug (1, Figure 5-30) and install.
9. Refill crankcase with 10 quarts (9.5 L) of 15W-40 motor oil through the fill area
(2, Figure 5-32).
Figure 5-32
Change Engine Fuel Filter Element and In-Line Fuel Filter
WARNING
!
Fuel is flammable. May cause severe injury or death.
Shut down the engine, extinguish all open flames and do not smoke while
filling the tank.
Always wipe up any spilled fuel.
1. Position the machine on a stable, level surface and shut OFF engine.
2. Place a container under the fuel filter (1, Figure 5-33) to capture any escaping
fuel and remove the filter using a filter wrench.
Figure 5-33
