SECTION 5 MAINTENANCE INSTRUCTIONS
5-34 DD-29/31HF/38HF Vibratory Asphalt Compactors
6. Install plugs (1, Figure 5-43) in each end of the spray bars.
7. Install drain plug (1, Figure 5-43) in the tank.
8. If machine is going back into service, fill tank with clean water, and install cap
(2, Figure 5-42).
Change Eccentric Lube
The eccentric lube oil in each drum must be changed at this interval.
WARNING
!
The oil must be at operating temperature for draining.
Use care, hot oil and components can burn.
1. Run the machine until oil is at operating temperature. Position the machine on
a level surface with the drum indexes (1, Figure 5-43) and drain plug (2)
oriented as shown.
Figure 5-43
2. Place a drain pan under the drain point and remove plugs
(2 and 3, Figure 5-43).
