Volvo DD29 - Service Functions

FUEL AND LUBRICANT SPECIFICATIONS SECTION 8
DD-29/31HF/38HF Vibratory Asphalt Compactors 8-5
SERVICE FUNCTIONS:
Table 8-2 Lubrication Table
NOTES:
1. See Section 5 for Initial Break-In Maintenance.
2. Multi-Purpose Premium Engine Oil: SAE 15W-40
3. Mobil DTE 15M Hydraulic Oil or equivalent ISO VG 46 VI 140 (min) above 12°
C (10° F). For temperatures below -12 °C (10° F), use Mobil SHC 624 Hydraulic
Oil or equivalent ISO VG 32.
4. Mobil SHC 630 or equivalent ISO VG 220
S - CHECK A - ADD G - GREASE C - CHANGE
D - DRAIN F - FILL CL - CLEAN AR - AS REQUIRED
SERVICE
INTERVAL
REF
NO.
DESCRIPTION SERVICE SPECIFICATIONS COMMENTS
10 HRS.
OR DAILY
1
3
ENGINE OIL
FUEL TANK
S, A
S, A
See (2) next page
#2 DIESEL FUEL
Fill To Dipstick Full
AR
50 HRS.
OR
WEEKLY
11
12
13
16
19
STEERING CYL BEARINGS
SWIVEL PINS
HYDRAULIC OIL
ECCENTRIC OIL
ENGINE COOLANT
G
G
S, A
S, A
S, A
MPG-EP2 GREASE
MPG-EP2 GREASE
See (3) next page
See (4) next page
Water/Anti-freeze
3 SHOTS EACH
3 SHOTS EACH
FILL TO SIGHT GLASS
FILL TO LEVEL HOLE
FILL TO FULL MARK
250 HRS.
OR
SEMI-
ANNUALLY
21
22
23
24
25
26
ENGINE OIL
ENGINE OIL FILTER
FUEL FILTER CARTRIGE
IN-LINE FUEL FILTER
PURGE LUBE CARRIER
HYDRAULIC OIL FILTER
D, F
C
C
C
G
C
See (2) next page
See (4) next page
See (2) (3) next page
See (2) (3) next page
MPG-EP2 Grease
See (2) (3) next page
8.5 L / 10.0 QT MAX.
Qty of 1
Qty of 1
Qty of 1
As Required
Qty of 1
1000 HRS.
OR
ANNUALLY
31
33
34
36
HYDRUALIC OIL TANK
ECCENTRIC LUBE
ENGINE COOLANT
FUEL TANK
D, C,L F
D, F
D, F
D, CL, F
See (3) next page
See (4) next page
Water/Anti-freeze
#2 DIESEL FUEL
84.9 L (22.4 GAL)
13.5 L (14.0 QTS)
FILL TO FULL MARK
68.1 L (18.0 GAL)
